NEW

CARVE ACE Stabilizer

Freeride, Freestyle, Wave, Downwind

€349,00

Tax included. Shipping calculated at checkout.

The CARVE ACE Stabilizer is a high-end carbon tail with a seamlessly integrated stabilizer for intermediate to expert riders seeking speed, agility, and ease of use in wing and parawing foiling. It excels across freeride, freestyle, wave, and downwind disciplines. Pairs with INFINITY ACE Front Wing.

Size: 170/325

170/325
190/235
190/395
210/395

Product variants

Hurry, only 5 items left in stock!

Sizes and Specifications

CARVE ACE Stabilizer	170 / 325	190 / 325	190 / 395	210 / 395
AREA	170 cm²	170 cm²	190 cm²	210 cm²
SPAN	330 mm	360 mm	360 mm	390 mm
CHORD	64 mm	66 mm	66 mm	68 mm
ASPECT RATIO	6.4	6.8	6.8	7.2
TAIL LENGTH	325 mm	325 mm	395 mm	395 mm
REC. TORQUE	M6x30 / 10 Nm	M6x30 / 10 Nm	M6x30 / 10 Nm	M6x30 / 10 Nm
PAIRS WITH	INFINITY ACE Front Wing 540, 690	INFINITY ACE Front Wing 840	INFINITY ACE Front Wing 990	INFINITY ACE Front Wing 1140, 1390

Scope of Delivery

The CARVE ACE monobloc carbon stabilizer comes with a cover and the screw for mounting to the monobloc front wing. All other foil parts can be purchased separately. Ideal set up see INFINITY ACE Foil Set.

Buy local

Pairs well with

Share:

Share

CARVE ACE Stabilizer

170/325

€349,00

Why a CARVE ACE Stabilizer?

Product description

The CARVE ACE Stabilizer is built for riders who demand maximum control and carving precision. Its profile delivers quick acceleration, exceptional grip for tight turns, and confident handling. It provides precise feedback through every turn while maintaining a smooth and efficient cruising.

Available in four sizes with different tail lengths, the CARVE ACE lets you fine-tune your setup for a tailored blend of maneuverability, stability, and speed.

Product details

Performance & Tech Features

Tight turns
The CARVE ACE provides excellent grip and control through tight turns. Its responsive design enables precise rail-to-rail transitions and powerful carving without compromising stability.

Fast acceleration
The efficient profile reduces drag and allows the foil to accelerate quickly. It responds immediately to rider input, making it easy to generate speed out of turns.

Easy cruising
The well-balanced design offers smooth, predictable handling. This makes the CARVE ACE comfortable and effortless to ride across a wide range of speeds and conditions.

Two tail lengths
Available in two tail lengths, the 325 mm offers increased agility and speed, while the 395 mm provides added stability and pitch control.

ACE – MANIAC Monobloc System
The advanced ACE monobloc construction integrates tail and stabilizer into a single carbon component for maximum efficiency, stiffness and clean hydrodynamic flow.

Size Specific Performance

CARVE ACE 170 / 325
WING FOIL | PARAWING FOIL | PRONE FOIL | KITE FOIL
Designed for the smallest INFINITY ACE, the CARVE ACE 170 delivers maximum control with a fast, minimal-drag profile. It accelerates instantly, supports early takeoffs and excels in tight, responsive carving for playful yet precise riding.

CARVE ACE 190 / 325
WING FOIL | PARAWING FOIL | PRONE FOIL
Designed for midsize INFINITY ACE, the CARVE ACE 190 combines speed, agility and control. With quick acceleration and a clean profile, it offers confident carving, smooth cruising and a highly responsive feel for performance-oriented all-round riding.

CARVE ACE 190 / 395
WING FOIL | PRONE FOIL | PARAWING FOIL | SUP FOIL
Designed for midsize INFINITY ACE, the CARVE ACE 190 combines speed, agility and control. With quick acceleration and a clean profile, it offers confident carving, smooth cruising and a highly responsive feel for performance-oriented all-round riding.

CARVE ACE 210 / 395
WING FOIL | PRONE FOIL | PARAWING FOIL
Designed for larger sizes of the INFINITY ACE, the CARVE ACE 210 balances speed with great low-end performance. It supports early takeoffs, sustained glide and maneuverable handling, making it a versatile choice for riders seeking efficiency, flow and confident carving.

ACE Foil Line

With the new CARVE ACE Stabilizer stabilizers, we’re introducing our advanced MANIAC Monobloc System, seamlessly integrating the front wing AND the stabilizer with their respective fuselages into dedicated single-piece carbon components. This streamlined, low-profile connection from tail to stabilizer optimizes hydrodynamics while eliminating an extra connection, increasing stiffness and performance even more.

CARVE ACE vs GLIDE ACE
The CARVE ACE is all about control, with its larger surface area and profile providing more grip, stability, and confidence through turns. In comparison, the smaller and more streamlined GLIDE ACE is focused on efficiency, reducing drag for maximum glide and speed while delivering a more radical, performance-oriented feel.

Michael Näf about stab development

Developing stabilizers is a science in its own right. In my opinion, the influence a stabilizer has on a foil setup is often underestimated. The right stabilizer can elevate a setup’s full potential, while the wrong choice can compromise performance.

We also invest significant effort into defining the ideal angle of attack, making shims unnecessary. This is why we develop and recommend foil setups that are carefully tuned to deliver outstanding and reliable performance.

CARVE ACE Stabilizer FAQs

Show all

What is the CARVE ACE Stabilizer?

CARVE ACE is a high-end monobloc stabilizer developed to maximize speed, maneuverability and ease of use in wing and parawing foiling. It is specifically designed to unlock the full potential of the front wing INFINITY ACE.

What riding style is it designed for?

Built for dynamic, high-performance foiling — tight carving, fast direction changes and confident control, from playful freestyle sessions to powerful wave and downwind runs.

What makes the CARVE ACE different?

The profile is optimized for grip, quick acceleration and direct, controlled response. Combined with the monobloc front wing, it delivers:
• Quick acceleration and speed
• Tight turns
• Playful feel
• Pop for experienced riders

What sizes are available?

• Projected Area: 170 cm², Tail Length: 325 mm
• Projected Area: 170 cm², Tail Length: 395 mm
• Projected Area: 190 cm², Tail Length: 395 mm
• Projected Area: 210 cm², Tail Length: 395 mm

Shorter tail → more playful and easier to pump. Longer tail → more stability and speed.

Who is it recommended for?

Paired with INFINITY ACE front wings, it is recommended for wing, parawing, prone, kite and SUP foil riders looking for maximum agility, speed, and a forgiving all-round foil for freeride, freestyle, wave, and downwind riding.
