MANIAC STRIDE
Pump Foil Entry & beyond
easy take-off and pumping, effortless glide
The MANIAC STRIDE is crafted to provide the easiest entry into the exhilarating experience of flying above the water. With high stability, effortless take-offs, and smooth pumping, it’s the perfect choice for anyone discovering pump foiling. Thanks to its excellent low speed lift and high efficiency, you’ll stay on the foil longer with less effort, accelerating your progression. The ultra-smooth, seemingly endless glide ensures that the MANIAC STRIDE remains enjoyable well beyond your first sessions. It is a foil that you will keep in your collection – perfect for windless days and sharing the fun with friends.
MANIAC STRIDE 2050
MANIAC Fuselage System
The MANIAC STRIDE is available on the fuselage system, providing a setup that is easy to assemble, highly reliable, and built to last. The MANIAC mast connection system features an interlocking design that minimizes flex and movement between the mast and fuselage, ensuring exceptional strength and a rigid, responsive feel. The front wing is securely mounted to the fuselage, delivering direct feedback and control on the water. Compatible with all masts and stabilizers in the MANIAC foil range.
Key features
For discoverer to intermediate
The high stability and early lift make it the ideal choice for discoverers attempting their first dock starts, while its efficiency and lightweight design make it a fun choice for experienced pump foilers.
Remarkable low speed lift
The foil generates lift and maintains flight at very low speeds, making take-offs easy and preventing foil stalls at lower speeds. This is especially crucial for discoverers.
Ultimate stability and control
The wide span of the MANIAC STRIDE front wing, paired with a stabilizer and our ultra-stiff mast options, keeps the rider in control, making the learning of take-offs and pumping as easy as possible.
Easy pumping and pop-ups
Designed for easy pumping and pop-ups, the MANIAC STRIDE makes dockstarts and flat water SUP foiling smoother than ever. With the perfect mix of stability and lift, you’ll get on the foil quickly with minimal effort.
Effortless glide
Minimal drag ensures superior efficiency, keeping you flying longer and reducing the need for constant pumping.
Lightweight foil
High modulus carbon used for front wing and stabilizer, premium aluminum quality used for fuselage and mast making it exceptionally light.
One tool assembly
The assembly screws provided is crafted from premium marine grade stainless steel, with a black coating for enhanced corrosion resistance. The entire foil can be assembled using a single Torque 30 tool, which is included with every MANIAC foil kit.
Indication screw length
The screw lengths are indicated by lines on the front wings and carbon masts, ensuring you always use the correct screws.
Information stabilizer and mast
MANIAC Carbon Stabilizer 190
The carbon MANIAC Stabilizer 190 balances the MANIAC STRIDE 2050 perfectly, offering excellent control while remaining fast and agile.
MANIAC Aluminum Mast 72
Unbeatable in lightweight, value and stiffness, this mast delivers outstanding performance. The thicker profile makes it ideal for pump foiling and SUP foiling – for excellent control and responsiveness.
MANIAC STRIDE Set
MANIAC STRIDE Set
2050
MANIAC STRIDE Front wing Carbon
2050
MANIAC Fuselage Alu
600
MANIAC Stabilizer Carbon
190
MANIAC Mast Aluminum
72
Specifications
MANIAC STRIDE Front wing
2050
Area
2050 cm2
Span
1400 mm
Chord
177 mm
Aspect Ratio
9.5
Screws
3x M8x35
Rec. Torque
17 Nm
MANIAC Stabilizer
190
Area
190 cm2
Span
360 mm
Chord
66 mm
Aspect Ratio
6.8
Screws
2x M6x20
Rec. Torque
10 Nm
MANIAC Aluminum Mast
72
Length
72 cm
Profile
18 mm
Weight (fully mounted incl. fuse adapter, base plate)
2.11 kg
Screws for Fuselage Adapter
2x M8x60
Screws for Base Plate
2x M8x40
Screws for Board mount
4x M8x27.5 / 4x T-nut
Rec. Torque
17 Nm
Accessories
Practical foil bag
The practical foil bag offers holders for 2 fuselages, 4 compartments for wings and masts, a zipper pocket for small parts and an address window.
MANIAC STRIDE Front wing
The MANIAC STRIDE Front wing can be purchased individually.
MANIAC Stabilizers
All MANIAC Stabilizers can be purchased individually.
MANIAC Masts
All MANIAC Masts can be purchased individually.
Scope of delivery
The MANIAC STRIDE Foil Set consists of a carbon front wing with cover, carbon stabilizer with cover, aluminum fuselage, aluminum mast (fully mounted with fuse adapter, anode and base plate), assembly screw set, mounting screw set with T-nuts, ENSIS Tool T30.
